This premiere travel regulator packs maximum performance into minimum space. A true featherweight second stage, the Compact is built from lightweight techno-polymers to eliminate jaw fatigue. Easy to pack and easy to dive, the Compact includes dive/pre-dive Venturi switch for managing freeflow and maximizing performance at depth.
TECHNICAL FEATURES 1ST STAGE - Balanced diaphragm (seal chamber for MC9SC) - 2 outlets HP 7/16 UNF - 4 outlets MP 3/8 UNF - Service pressure: 300 bar (4350 psi) DIN version, 232 bar (3365 psi) Yoke version - Calibration pressure: 10 Bar - Brass body Electroless Nickel plated - High capacity conical filter electroless nickel plated - Aisi 316 removable nozzle - Hyper-balancing - Anti-pressure drop pneumatic spring - Setting spring: stainless steel with micropeening treatment - Replaceable cylinder with anti-friction and anti-corrosion properties - Elastomer protector - Flow rate: 4500 l/min - Yoke version weight: 590 gr - Din version weight: 450 gr TECHNICAL FEATURES 2ND STAGE - Downstream system - Adjustable venturi effect - Patented antifriction lever - Big purge button - Anti-scratch surface - Bayonet-type cap holder with security lock - Removable exhaust tee - Weight without hose: 135 gr COMBINATION PERFORMANCE - Average Cracking effort 6 mbar - Average breathing effort 1 J/l JACKETED HOSE extremely light and flexible weight: 153 gr CERTIFICATION EN250/2000
